European Standard Ob chav Girder Gantry Crane

European Standard Ob chav Girder Gantry Crane Nqe MG hom European txheem gantry crane nrog nqe lauj tsim thiab tsim los ntawm European FEM advanced txuj. Muab piv rau MG hom crane. nws cov peev txheej tau yog 3 ~ 20t, qhov tseem ceeb ntawm qhov yog ntawm European trolley ....

Xa kev nugTsham tam sim no
Txhawb tshuaj

European Standard Ob chav Girder Gantry Crane


Kev piav qhia

Lub MG hom European txheem gantry crane nrog sib ntsib yog tsim thiab manufactured los ntawm European FEM advanced txuj. Muab piv rau MG hom crane. nws cov peev txheej tau yog 3 ~ 20t, qhov tseem ceeb ntawm qhov yog ntawm European trolley. Tag nrho cov trolley tau reducer tawv hniav ntau. peb-hauv-ib tsav. saws PLC + zaus hloov tshuab, uas yog ua kom txoj kev ua tiav ntawm qhov khoom ua tau zoo, hos qhov nyhav tag nrho ntawm qhov crane qeeb tshaj 15% thiab lub log xovxwm 10 ~ 20%. Cov khoom no siv tau los siv hauv cov hoobkas, tsheb thauj khoom. warehouse thiab lwm qhov chaw rau cov khoom thauj.


Nta

1. Teeb tus kheej qhov ceeb thawj

2. European FEM advanced tsim qauv

3. Triad tsav & kev ua haujlwm siab

4. PLC & Tshaj Tawm Tsawg Hloov Tawm Tshuab


Specification


Capacity (tuj)

5

10

16 / 3.2

20/5

32/5

50/10

Kev ncua (m)

18, 22, 24, 26, 30, 35

Lifting qhov siab (m)

10, 11, 12

Ua haujlwm hauv chav kawm

A5

Tswj txoj kev

Alarm tswj los yog chaw taws teeb tswj

Lub zog fais fab

380V 50HZ 3phase (Yuav muab nws li koj li)

Trolley lifting mechanism

Lifting ceev
(m / min)

Main nuv

11.3

8.5

7.9

7.2

7.5

5.9

Pab nqai

-

-

14.6

15.4

15.4

10.4

Trolley travelling

Mus ncig teb chaws ceev (m / min)

37.3

35.6

36.6

36.6

37

36

Crane mus ncig teb chaws mechanism

Mus ncig teb chaws ceev (m / min)

37.3

39.7

37.3

39.7

39.4

38.5

Lub cev muaj zog zog (KW)

40.8-51.8

41.5-52.8

80-77

84-81

99.3-117.3

126.5

Hlau taug qab pom zoo

43kg / m

43kg / m lossis QU70
